Ip66 Waterproof 40W RGB High Power LED Flood Light With Lumileds Luxeon5050/3030 Chip
Features:
1. Adopting to high power integrated RGB LED, which ensures light is more uniform,light efficiency is higher.
2. Standard DMX512 signal input, internal control and external control.
3. Unique wireless control, control distance up to 50m
4. Built-in 350mA constant current driver design to ensure light for a stable work
5. Using high transmittance tempered glass,transimittance 93%
6. Complying with ROHS,absolutely not contain mercury or other harmful substance
7. Lifespan is over 35000 hours
8. May realize "online address grogramming
Applications:
- It is applicable to playground lighting ,warehouse lighting, plaza lighting, tunnel lighting and so on.
- New Installation or Replace the traditional High Pressure Sodium Lamp, High Pressure Mercury Lamp, and Metal Halide Street Lamps. Etc.
Parameter Performance:
| Material | Die-cast aluminum |
| Input Voltage | DC24V |
| Power Efficiency | ≥90% |
| Beam Angle | 150º 65º |
| Led chip | Epistar,Bridgelux,Epileds |
| Power(Single LED) | 1W |
| LED Qty. | 9/18/30/48 |
| Control | DMX512/1990 /RF |
| Signal Line | With IP68 waterproof gold-plated terminal connector |
| RF Frequency | 335MHz |
| RF Distance | 30-50m |
| IP Code | IP65 |
| Operatinal condition | Temperature:-30℃~50℃
Humidity:10%-90%RH |
| Lifespan | >35000hrs |
Technical Data:
| Model | Product Dimension(mm) | Power (W) | LED luminous flux | Control mode | N．W |
| LY-FL1010RGB-D/R | L120xW95xH130 | 10 | Red: 100-140lm
Green: 200-230lm
Blue:30-50lm | DMX512/RF | 0.51KG |
| LY-FL1020RGB-D/R | L205xW157xH250 | 25 | Red: 220-300lm
Green: 400-480lm
Blue:70-110lm | DMX512/RF | 1.8KG |
| LY-FL1030RGB-D/R | L205xW157xH250 | 35 | Red: 380-480lm
Green: 680-780lm
Blue:120-180lm | DMX512/RF | 2.03KG |
| LY-FL1050RGB-D/R | L250xW180xH310 | 55 | Red: 620-780lm
Green: 1100-1250lm
Blue:200-260lm | DMX512/RF | 2.91KG |
Operation and storage condition:
l Operation Ambient Temperature -40 to +50°C, Relative Humidity 20~90%
l Input Voltage 100~240V AC, 50/60Hz
l Storage Ambient Temperature -40 to +65°C, Relative Humidity 5~95%
l Mounting Height : Suitable for 3~10m height
Assembly and Installation:
l Assembly-Electricity
Ø Blue : Neutral
Ø Brown : Line
Ø Yellow-Green : Ground
Package:
Inner box Size: 246mm×390mm×135mm
Outer box Size: 261mm×405mm×305mm (2 PCS LED Flood Light)
